Wedge Anchors - BZP

An internally threaded permanent fixing for use in concrete and solid stone (not suitable for brick or block).
It is imporant to set anchors with the correct setting tool to ensure correct installation.
Accepts metric threaded bolts or studding.
Use in dry conditions.

No detailed specifications are available for this product.

Click on any of the following links to download the file.

Code Description Size/Ref Drill Diameter Pack Qty Minimum Hole Depth Bolt Diameter Internal Thread Length Min Hole Depth (mm) Internal Thread Length (mm) Price
03101 M6x25mm BZP Wedge Anchors Drop in Anchor Zinc and Yellow M6x25 8 100 32 M6 13 32 13
03102 M8x30mm BZP Wedge Anchors M8x30 10 100 32 M8 13 32 13
03103 M10x40mm BZP Wedge Anchors Drop in M10x40 12 100 53 M10 18 42 15
03104 M12x50mm BZP Wedge Anchors M12x50 15 50 53 M12 18 53 18
03105 M16x65mm BZP Wedge Anchors M16x65 20 25 70 M16 23 70 23
03106 M20x80mm BZP Wedge Anchors M20x80 24 25 85 M20 32 85 32
Please login to see prices..
